Sequential Logic

Name: Sequential Logic
Brand: Taylor & Francis Inc
Price: 302.75 AUD
Availability: BackOrder

Analysis and Synthesis

By: Joseph Cavanagh

Write A Review

Hardcover | 2 June 2006 | Edition Number 1

At a Glance

Hardcover
912 Pages

Dimensions(cm)
25.4 x 17.8 x 5.08

Hardcover

RRP $326.00

$302.75

or 4 interest-free payments of $75.69 with

Available for Backorder. We will order this from our supplier however there isn't a current ETA.

Until now, there was no single resource for actual digital system design. Using both basic and advanced concepts, Sequential Logic: Analysis and Synthesis offers a thorough exposition of the analysis and synthesis of both synchronous and asynchronous sequential machines.

With 25 years of experience in designing computing equipment, the author stresses the practical design of state machines. He clearly delineates each step of the structured and rigorous design principles that can be applied to practical applications. The book begins by reviewing the analysis of combinatorial logic and Boolean algebra, and goes on to define sequential machines and discuss traditional and alternative methods for synthesizing synchronous sequential machines. The final chapters deal with asynchronous sequential machines and pulse-mode asynchronous sequential machines. Because this volume is technology-independent, these techniques can be used in a variety of fields, such as electrical and computer engineering as well as nanotechnology.

By presenting each method in detail, expounding on several corresponding examples, and providing over 500 useful figures, Sequential Logic is an excellent tutorial on analysis and synthesis procedures.

Industry Reviews

"By presenting each method in detail, expounding on several corresponding examples, and providing over 500 useful figures, this book is an excellent tutorial on analysis and synthesis procedures."

- In Zentralblatt Math, 2008/2009, Vol. 1131

Shipping

	Standard Shipping	Express Shipping
Metro postcodes:	$9.99	$14.95
Regional postcodes:	$9.99	$14.95
Rural postcodes:	$9.99	$14.95

How to return your order

At Booktopia, we offer hassle-free returns in accordance with our returns policy. If you wish to return an item, please get in touch with Booktopia Customer Care.

Additional postage charges may be applicable.

Defective items

If there is a problem with any of the items received for your order then the Booktopia Customer Care team is ready to assist you.

For more info please visit our Help Centre.

You Can Find This Book In

Non-Fiction Computing & I.T.Computer Science Systems Analysis & Design Engineering & Technology Electronics & Communications Engineering Electronics Engineering Circuits & Components Electronic Devices & Materials Microprocessors Information Technology General Issue Energy Technology & Engineering

Electrical Engineering Environmental Science

Preface	p. xi
Review of Combinational Logic	p. 1
Number Systems	p. 2
Binary Number System	p. 3
Octal Number System	p. 4
Decimal Number System	p. 4
Hexadecimal Number System	p. 5
Number Representations	p. 8
Sign Magnitude	p. 8
Diminished-Radix Complement	p. 9
Radix Complement	p. 10
Boolean Algebra	p. 12
Minimization Techniques	p. 18
Algebraic Minimization	p. 19
Karnaugh Maps	p. 20
Quine-McCluskey Algorithm	p. 28
Logic Symbols	p. 35
Analysis of Combinational Logic	p. 37
Synthesis of Combinational Logic	p. 42
Multiplexers	p. 45
Decoders	p. 47
Encoders	p. 53
Comparators	p. 54
Storage Elements	p. 56
SR Latch	p. 57
D Flip-Flop	p. 57
JK Flip-Flop	p. 59
T Flip-Flop	p. 60
Programmable Logic Devices	p. 61
Programmable Read-Only Memories	p. 61
Programmable Array Logic	p. 64
Programmable Logic Array	p. 67
Problems	p. 69
Analysis of Synchronous Sequential Machines	p. 77
Sequential Circuits	p. 78
Machine Alphabets	p. 79
Formal Definition of a Synchronous Sequential Machine	p. 82
Classes of Sequential Machines	p. 89
Combinational Logic	p. 89
Registers	p. 93
Counters	p. 98
Moore Machines	p. 105
Mealy Machines	p. 110
Asynchronous Sequential Machines	p. 121
Additional Definitions for Synchronous Sequential Machines	p. 123
Methods of Analysis	p. 136
Next-State Table	p. 136
Present-State Map	p. 137
Next-State Map	p. 137
Input Map	p. 138
Output Map	p. 140
Timing Diagram	p. 141
State Diagram	p. 143
Analysis Examples	p. 146
Complete and Incomplete Synchronous Sequential Machines	p. 161
Complete Synchronous Sequential Machines	p. 161
Incomplete Synchronous Sequential Machines	p. 162
Problems	p. 166
Synthesis of Synchronous Sequential Machines 1	p. 181
Synthesis Procedure	p. 182
Equivalent States	p. 183
Synchronous Registers	p. 197
Parallel-In, Parallel-Out Registers	p. 197
Parallel-In, Serial-Out Registers	p. 201
Serial-In, Parallel-Out Registers	p. 205
Serial-In, Serial-Out Registers	p. 208
Linear Feedback Shift Registers	p. 212
Combinational Shifter	p. 218
Synchronous Counters	p. 223
Modulo-8 Counter	p. 223
Modulo-10 Counter	p. 234
Johnson Counter	p. 245
Binary-to-Gray Code Converter	p. 248
Moore Machines	p. 254
Mealy Machines	p. 277
Moore-Mealy Equivalence	p. 298
Mealy-to-Moore Transformation	p. 298
Moore-to-Mealy Transformation	p. 307
Output Glitches	p. 307
Glitch Elimination Using State Code Assignment	p. 312
Glitch Elimination Using Storage Elements	p. 319
Glitch Elimination Using Complemented Clock	p. 323
Glitch Elimination Using Delayed Clock	p. 326
Glitches and Output Maps	p. 333
Compendium of Output Glitches	p. 339
Problems	p. 344
Synthesis of Synchronous Sequential Machines 2	p. 361
Multiplexers for [delta] Next-State Logic	p. 361
Linear-Select Multiplexers	p. 363
Nonlinear-Select Multiplexers	p. 377
Decoders for [lambda] Output Logic	p. 400
Programmable Logic Devices	p. 412
Programmable Read-Only Memory	p. 413
Programmable Array Logic	p. 421
Programmable Logic Array	p. 432
Field-Programmable Gate Array	p. 437
Microprocessor-Controlled Sequential Machines	p. 448
General Considerations	p. 449
Mealy Machine Synthesis	p. 453
Machine State Augmentation	p. 461
Moore and Mealy Outputs	p. 466
System Architecture	p. 467
Multiple Machines	p. 477
Sequential Iterative Machines	p. 481
Error Detection in Synchronous Sequential Machines	p. 489
Problems	p. 500
Analysis of Asynchronous Sequential Machines	p. 519
Introduction	p. 520
Fundamental-Mode Model	p. 522
Methods of Analysis	p. 526
Hazards	p. 553
Static Hazards	p. 553
Dynamic Hazards	p. 568
Essential Hazards	p. 572
Multiple-Order Hazards	p. 577
Oscillations	p. 578
Races	p. 582
Noncritical Races	p. 583
Cycles	p. 586
Critical Races	p. 586
Problems	p. 590
Synthesis of Asynchronous Sequential Machines	p. 607
Introduction	p. 608
Synthesis Procedure	p. 610
State Diagram	p. 612
Primitive Flow Table	p. 616
Equivalent States	p. 632
Merger Diagram	p. 645
Merged Flow Table	p. 656
Excitation Maps and Equations	p. 661
Output Maps and Equations	p. 691
Logic Diagram	p. 710
Synthesis Examples	p. 716
Mealy Machine with Two Inputs and One Output	p. 716
Mealy Machine with Two Inputs and One Output Using a Programmable Logic Array (PLA)	p. 727
Moore Machine with One Input and One Output	p. 735
Mealy Machine with Two Inputs and Two Outputs	p. 741
Mealy Machine with Three Inputs and One Output	p. 755
Mealy Machine with Two Inputs and Two Outputs	p. 765
Problems	p. 777
Pulse-Mode Asynchronous Sequential Machines	p. 807
Analysis Procedure	p. 809
SR Latches as Storage Elements	p. 810
SR Latches with D Flip-Flops as Storage Elements	p. 817
Synthesis Procedure	p. 823
SR Latches as Storage Elements	p. 823
T Flip-Flops as Storage Elements	p. 830
SR-T Flip-Flops as Storage Elements	p. 836
SR Latches with D Flip-Flops as Storage Elements	p. 844
Problems	p. 850
Answers to Selected Problems	p. 861
Index	p. 889
Table of Contents provided by Ingram. All Rights Reserved.
